Used Dental CAD/CAM Acquisition Unit | CEREC AC Omnicam

used dental cad/cam acquisition unit | cerec ac omnicam


The CEREC AC Omnicam is a computerized acquisition unit that uses a camera to capture a digital image of a tooth or impression model. This image can then be manipulated by the CEREC software and sent to an onsite CEREC milling machine or an offsite dental lab where a crown or restoration is milled.

Unlike the Redcam and Bluecam, the Omnicam requires no powder. It allows users to differentiate among different materials. As the camera moves over the teeth, a photo-realistic image is displayed in full color with crisp clarity.

  • Powder-free
  • Slim, rounded camera handpiece
  • Captures images in 2D and 3D
  • Anti-shake feature
  • Color-Streaming feature
  • Provides an excellent patient education tool
  • Allows continuous capture of the oral cavity
  • Allows for easy rotation of the camera in the intraoral space
Technical Specifications:
  • Measuring technique: Triangulation
  • Light source: White LED, unpolarized, visible spectral range
  • Processor: Intel i7 5820K
  • Computer memory: 2 x 8GB, 2133MHz DDR4-RAM
  • Network card: Ethernet 10/100/1000 Mbit/s onboard
  • WLAN card: TP-Link TL-WDN4800
  • Operating system: Windows Embedded Standard 7, 64Bit
