used dental curing lights | 3m/unitek ortholux xt

The Unitek Ortholux XT (also known as XL-3000) uses a high-intensity blue light source needed for effective curing. The built-in light intensity meter verifies light output level, allowing you to test light output before each use.

The Ortholux XT's rotating nose cone allows for easy light-guide adjustment with a flip of a finger. Other features include an automatic timer setting on the handpiece (10, 20, 30, 40 seconds, or extended operation), a 60° tip angle for easy access into the mouth, and a standard 13mm light guide and eyeshield (8mm light guide also available).


  • Built-in radiometer
    Hand-piece holder
  • Extra bulb holder
    • Faster Curing Times
  • Allows for easy replacement of bulb when necessary
  • Allows for easy storage when not in use
  • Verifies light output level
  • Allows test light output before each use
  • Allows easy access into the mouth
Technical Specifications: Power Source:
  • Requires wall outlet for power and is not rechargeable
  • Voltage: 110/120 V 50/60 Hz 0.9 A
  • Light Source: 75 Watt Tungsten Halogen Bulb
  • Bulb Voltage: 12V
  • Cooling: Air Fan
  • Recommended Curing Time: 40 seconds
  • Measured Irradiance (mW/cm2 ): 544 (+/-17)
