used dental delivery systems | adec porta-cart 3406


The A-dec Porta-Cart is a self-contained mobile dental unit designed for field or operatory use. All facilities required for the practice of general dentistry are provided for both the doctor and the dental assistant.

It is built around A-dec's Century II automatic control system for 2 handpieces with air and water coolant. Oral evacuation is provided by a built-in Air Vacuum System (AVS) and an Air Saliva Ejector (ASE).

A pressurized two-quart tank supplies water for handpiece coolant and the syringe. The only external connection required is the air supply. A ten foot air supply hose is furnished for this purpose. It may be connected to a compressor delivering dry, filtered air at 80-100 psi @ 4 cfm, or to bottled gas (carbon dioxide or nitrogen) regulated to 80-100 psi.

  • Water/air syringe
  • High Vac Suction and Saliva ejector
  • Collapsible cart, rolling casters
  • High speed and low speed operations
  • Self-contained mobile dental unit
  • Air Coolant Flow Control
  • Individual Water Coolant Flow Control for each Handpiece for easier use
  • Long-lasting metal construction optimal for travelling
  • Strong built parts for damage reduction from being buffetted around
  • Only requires access to compressed air for operation
  • Portable dental operating and treatment unit
  • The unit can also use bottled gases (nitrogen or cabon dioxide)
  • Observe each warning, caution and note in the user manaul. The use of compressed air and pressurized water may be hazardous to the personnel
Technical Specifications:
  • Case Dimensions (Inch): 22.5 L x 20 W x 11.5 H
  • Unit Dimensions (Inch): 18.3 L x 15.5 W x 32 H
  • Tray Dimensions (Inch): 15.18 L x 10.58 W
  • Water Pressure : Approx. 30 - 40 psi
  • Air Pressure: Approx. 60 - 80 psi
  • Nitrogen/carbon dioxide Pressure: Approx. 80 - 100 psi
  • Air Supply Tube Length: 10 ft
  • Weight: Approx. 70 lbs
