Used Dental Handpieces | Kerr Electrotorque Plus
ELECTROtorque plus LUX Motor Kit is an air/electric conversion kit for any delivery unit. It is used with KaVo GENTLEpower LUX LP or other E-type attachments.
Features:
- Shortest & lightest electric motors
- Features SAFEdrive and MULTI LED
- Automatic pressure regulation for plug & prep capability
- Patented brushless motor
- Two programmable speed settings—can be individually set by the user
- Digital speed control, forward/reverse operation
- Water spray can be conveniently adjusted at the motor
- Motor speed range 100 to 40,000 rpm
- Entire speed range 27 to 200,000 rpm
- Motor is autoclavable
- Has the ability to feather motor speed with the rheostat
Benefits:
- Powerful, constant torque for faster and more precise preprations
- Small, easy to install control box—fits in virtually any delivery system
- Unit can be calibrated to existing air pressure of the dental unit for optimized performance
- Speed can be feathered with existing rheostat through entire pre-selected speed range
- Light weight
- Provides illumination and water for all procedures
- Easy handpiece maintenance
- No brushes to exchange (no down time)
- Whisper quiet, less noise than brush motors
- Less vibration than brush motors (smoother, more concentric cut)
Technical Specifications:
-
Width x Height x Depth: 4.92" x 2.16" x 5.90"
-
Weight: 2.75 ounces
-
Speed range : 100 to 40 000 rpm
-
Clockwise rotation : 40,000 rpm
-
CCW rotation : 40,000 rpm
-
Permissible ambient temperature range : -20°C to +70°C / -4°F to +158°F
-
Operating time: 0.5 minutes
-
Pause time : 9 minutes
-
System pressure : 1.8 to 5 bar / 26 to 72.5 psi
-
Spray air : 1.0 to 2.5 bar / 14.5 to 36.2 psi
-
Spray water : 0.8 to 2.0 bar / 11.6 to 29 psi
-
Torque : Max. 3 Ncm
-
Motor voltage : 22 V AC
