Used Dental Intraoral Camera | Schick USBCam

Current Listings

USBCam is the first self-contained intraoral camera to combine the benefits of full motion video with the latest digital technology. The Schick USBCam Intraoral Digital Camera supplies clean illumination from a brilliant LED source. Power on /off and one-click capture buttons are set right into the handpiece.

USBCam is powered from your computer's USB port (no external power supply needed) and compatible with DirectX, Microsoft's longstanding technology for video performance.  So,  installation and setup is a breeze.

  • Focus free optics
  • One click capture button
  • LED light source
  • Standard USB connection
  • Integrated frame capture button
  • Lightweight design and smooth contours
  • Plugs directly into your computer -- no separate power supply required
  • Comfortable to hold and easy to use.
  • Capture the angles and images you need with the click of a button
  • Makes video capture a simple one-step operation
  • Provides reliable, long-life  illumination.
  • Fast and easy hardware setup
  • No special "frame grabbing" video card or additional  device driver required
  • Portable, convenient, and user-friendly
Technical Specifications:
  • Imager:: 1/4-inch progressive scan CCD
  • Effective Pixel Layout:: 659 (H) x 494 (V)
  • Video Output:: USB 1.1 compliant full motion digital
  • Focus range : 8 - 40 mm (0.31 - 1.6 in)
  • Focus type : Fixed
  • Input electrical ratings : 5VDC @ 400mA
  • Equipment type : Type BF equipment (on handpiece)
  • Fuses : 63VDC/VAC, 1A fast blow fuse
  • Restricted service statement : Unless otherwise specified, this unit should be serviced only by the manufacturer. It contains no user-serviceable parts.
  • External power supply : None
  • Maximum cable length : 5 m (5.5 yds)
  • Handpiece weight : 60 g (2.1 oz)
  • Software Required:: CDR Software, CDR Video Manager for DirectX
